Product name : Two Color Sealed Ink Cup Pad Printing Machine
Machine Type: Two Colors , Closed Ink cup
Inkcup Size: OD 90 ID 82 H12mm
Plate Size: 100*250mm
Drive : Pneumatic , Semi-automatic
Application : Garments, Pen, cap of bottle,
watches, cameras, pharmaceutical and medical equipment etc.
Machine Standard Features:
Pad printing is a printing process that allows one to print writings, graphics, drawings, logos and decorations on almost any objects, including on concave, convex or generally irregularly shaped surfaces.
Engyprint machines are all comply to CE standard, major accessories are all imported from overseas, that’s why our pad printers can work stable and excellent in customers factory.
ENGYPRINT Two Color Inkcup Pad Printing Machine Specifications:
|Plate size||250 x 100mm (10”x4”)|
|Ink cup size (diameter)||ID82 x OD90 mm (3.23”x3.54”)|
|Max. printing size||Ø70 mm (Ø2.75 mm)|
|Printing capacity||1500 cycles/hour|
|Front & back working stroke||150 mm|
|Air requirement||5 bar (72.5 psi)|
|Main voltage||110V/220V 50/60Hz 40W|
|Machine size||L780 x W500 x H1350 mm|
|Crated size||L1030 x W750 x H1600 mm|
