Two Color Open Tray Pad Printer For Ceramic bowl

Product name : Two Color Open Tray Pad Printer For Ceramic bowl

Machine Type: Two Color , Open Tray

Plate Size: 100*100mm or 100*150mm or customized

Drive : Pneumatic , Semi-automatic

Machine Brand: ENGY

Application : Toys, Ceramics bowls, glasses etc.

Product Details

ENGYPRINT Two Color Open Tray Pad Printing Machine Specifications:

Model NO. EN-Y125/2S EN-Y160/2S
Plate size 100x100mm 100x150mm
Max. printing size 80*80mm 80*130mm
Printing capacity 1600 cycles/hour 1400 cycles/hour
Air requirement 5 bar (72.5 psi) 5 bar (72.5 psi)
Main voltage 110V/220V 50/60Hz 40W 110V/220V 50/60Hz 40W
Machine size L700xW550xH1250mm L850xW550xH1350mm
Net Weight 82kg 100KG





Machine Standard Features:

●  Different machine stroke are available to meet diversify product printing demand.

●  Semi automatic, microprocessor control system, electro-pneumatic control.

●  Independent adjustment of up and down, front and back stroke.

●  Independent X, Y printing pad adjustment.

●  Open Tray base with X, Y, R adjustment, worktable X,Y adjustment.

●  Foot pedal operation for single cycle.

●  Complying with CE safety standards.



This open tray pad printer enjoy great reputation in the industry because it’s very economic and easy operation.

Open tray pad printer normally assembled with thick plate for printing, but it’s also fine if client hope to use water washable photo polymer pad printing plate or aluminum plate, the plate base will be added with magnets.
