Six Color Closed Ink Cup Pad Printer With Conveyor For Golf Ball

Product name :  Six Color Closed Ink Cup Pad Printer With Conveyor

Machine Type: Six Color , Closed Ink cup

Inkcup Size: OD100 ID 90 H12mm

Fixture quantity: 18

Plate Size: 100*250mm or customized

Drive : Pneumatic , Semi-automatic

Machine Brand: ENGY

Application: Golf Ball, toys, base ball, daily necessities, metal parts etc.

Product Details

ENGYPRINT Closed Ink Cup Pad Printing Machine With Conveyor Specifications:

Model NO.: EN-C160/6A
Plate size : 100*250mm
Max. printing size: 60*110mm
Ink Cup Size: OD100 ID 90 H12mm
Printing capacity: 800 cycles/hour
Air requirement : 5 bar (72.5 psi)
Main voltage: 110V/220V 50/60Hz 40W
Machine size: L1200*W1100*H1350mm
Net Weight: 260kg


Machine Standard Features:

●  Different machine stroke to meet diversify products printing demand.

●  Closed ink cup printing system, clean and environmental friendly.

●  Microprocessor control, low noise, stable performance, simple operation.

●  Conveyor design can speed up the printing speed compare to a pad printer with shuttle for multi-colors printing.

●  Widely applied in many industries including : Medical parts, gifts, promotion items ,school supplies , baby products etc.

●  Complying with CE safety standards.

This machine is highly recommended to be used for golf ball printing.

In order to get a closed ink cup pad printer ready for printing, it is necessary to prepare a air compressor , ink , related consumables including: pad which is made according to the sample and the logo, ink cup( assembled with ceramic ring or carbide ring ), plate with logo(by etching or by engraving ) , fixture ( to hold the product during printing process ) and products.


Engy print can provide the one stop solutions for pad printer, including pad printer, the related consumables and the plate making technologies
