Model Number:EN-B175/2
Machine Type: Two Color , Closed Ink cup
Inkcup Size: OD 90 ID 82 H12mm
Plate Size: 100*250mm
Drive : Pneumatic , Semi-automatic
Application : Garments, Pen, cap of bottle,
watches, cameras, pharmaceutical and medical equipment etc.
Machine Standard Features:
If anyone is looking for a 2 color pad printer for logo printing, it is recommended to use this machine because:
ENGYPRINT Two Color Inkcup Pad Printing Machine Specifications:
| Model No. | EN-B175/2 |
| Plate size | 250 x 100mm (10”x4”) |
| Ink cup size (diameter) | ID82 x OD90 mm (3.23”x3.54”) |
| Max. printing size | 100 x 75 mm (2.95″x2.95″) |
| Printing capacity | 1400 cycles/hour |
| Drive | Pneumatic |
| Front & back working stroke | 175 mm |
| Air requirement | 5 bar (72.5 psi) |
| Main voltage | 110V/220V 50/60Hz 40W |
| Machine size | L800 x W750 x H1450 mm |
| Crated size | L1130 x W1150 x H1680 mm |
| Net Weight | 148kg |
| Gross Weight | 198kg |
Two Color Pad Printer With Shutter For Bottle Cap
Two Color Pad Printer With shuttle for Coffee Machine
One Color Pad Printer for Garments, Tagless Logo
